PAUS PTK 31 Trailer Crane
With a lifting capacity of up to 1,600 kg and an extension length reaching 31 meters, the Paus PTK 31 trailer crane is purpose-built for the needs of roofers and carpenters. Its innovative nestable aluminum profiles ensure smooth and reliable handling of heavy transport tasks. Thanks to four independently adjustable telescopic outriggers, the crane can be safely positioned even on confined, uneven ground, steps, or elevated kerbs.
Highlights & Features
• Extendible fly-jib with hydraulic articulated joint
• Gradient climbing capability
• Four individually folding telescopic supports
• Hydraulic travel drive with remote control
• Ergonomic control panel with real-time data display
• Retractable drawbar, ergonomic control panel
Details
Extended length up to 31 m
Maximum payload of 1.6 tonnes
Fully hydraulic fly jib
Closed aluminium profiles for even greater stability
Easy to set up, thanks to automatic self-levelling
Lowerable rear axle makes it easier to manoeuvre
Extremely easy to handle thanks to radio remote control
Cathodic-dip-coated chassis including powder coating and cavity sealant
Large lateral range with maximum stability
At a gross weight of 3.5 tonnes, the Skyworker can be easily transported using a car
Documentation
Technical Data
Options
Environmentally friendly 400 V electric drive
Zero emissions and quiet
Can be used within halls
Easy to dismantle thanks to quick-coupling connections and forklift slots
Protects people during work at height
Retractable type fall arrester (in accordance with EN 360) including safety harness is hooked into load hook adapter
Working radius of the retractable type fall arrester starting from the hook tip: 10 metres
Radio remote control is connected to the crane by cable—visual contact between operator and person being protected
Current status of the personal fall protection equipment can be read on the display
Protection against operator error through control-side monitoring of all safety-related requirements
400V electric drive trailer crane
Personal protective equipment trailer crane
Special painting trailer crane
Tip extension trailer crane
Base plates trailer crane
Tile distributor trailer crane
Aluminium tipping bucket trailer crane
Aluminium roof tile clamps trailer crane
Aluminium long material fork trailer crane
Slings trailer crane
Different aluminium palette fork up to 1,200 kg payload trailer crane
Solar module distributor trailer crane
